made up of anodised aluminum or S.S. sheet. The gap between inner and outer chamber is filled with high grade
glass wool to avoid thermal losses. Beaded heating elements are placed in ribs, at bottom and sides. Inner chamber
is provided with ribs for adjusting perforated selves to convenient height.
The door is fitted with glass viewing window to facilitate inspection of sample without disturbing the test
temperature. Temperature is controlled by hydraulic type capillary thermostat from ambient to 90°C ± 0.5°C.
An L- shaped. prismatic thermometer is fitted to unit for reading the chamber temperature. Air ventilators are
also provided on the side of unit. To work on 220/230 volts A.C. Supply.
| Size inside chamber : (W x D x H) | Aluminum Thermostat | Aluminum Digital | S.S. Thermostat | S.S. Digital |
|---|---|---|---|---|
| 300 mm x 300 mm x 300 mm | 11,600/- | 17,700/- | 14,300/- | 21,000/- |
| 355 mm x 355 mm x 355 mm | 13,000/- | 20,300/- | 17,900/- | 23,300/- |
| 455 mm x 455 mm x 455 mm | 19,000/- | 24,700/- | 23,500/- | 27,000/- |
| 455 mm x 455 mm x 605 mm | 24,000/- | 25,400/- | 27,000/- | 37,000/- |
| 605 mm x 605 mm x 605 mm | 27,000/- | 28,300/- | 38,500/- | 50,000/- |
| 605 mm x 455 mm x 910 mm | 36,500/- | 41,500/- | 41,300/- | 60,000/- |
| 605 mm x 605 mm x 910 mm | 49,300/- | 54,400/- | 56,000/- | 71,000/- |
| Optional Accessories | ||||
| 1. Air circulating fan | 2,600/- | |||
| 2. Microprocessor PID Control | 10,400/- | |||
| 3. Digital timer | 6,500/- | |||
